Soba Audio

Soba Audio O.P.T.(Output Transformer) list :

Single Ended:

EL84,SV83,6BQ5,6V6,6P15P,6P1P 6 watt 5200 ohm - 1,00 kg.

6L6,KT66,6P3C 12 watt 2500 ohm - 1,75 kg.

EL34,KT88 15 watt 3000 ohm - 2,20 kg.

%30 , %33 , %40 Ultra Linear options.

Parallel Single Ended (x2) :

EL84,SV83,6BQ5,6V6,6P15P,6P1P 12 watt 3000 ohm - 1,75 kg.

6L6,KT66,6P3C 24 watt 1500 ohm - 2,50 kg.

EL34,KT88 30 watt 1800 ohm - 3,00 kg.

%30 , %33 , %40 Ultra Linear options.

Push Pull :

EL84,SV83,6BQ5,6V6,6P15P,6P1P 18 watt (centre tapped) 8000 ohm - 2,20 kg.

6L6,KT66,6P3C 24 watt (centre tapped) 4000 ohm - 2,50 kg.

EL34,KT88 36 watt (centre tapped) 5000 ohm - 3,60 kg.

EL34,KT88 50 watt (centre tapped) 5000 ohm - 4,50 kg.

%30 , %33 , %40 Ultra Linear options.

Parallel Push Pull (x2) :

EL84,SV83,6BQ5,6V6,6P15P,6P1P 50 watt (centre tapped) 4800 ohm - 4,50 kg.

6L6,KT66,6P3C 70 watt (centre tapped) 2400 ohm - 5,50 kg.

EL34,KT88 100 watt (centre tapped) 2900 ohm - 6,60 kg.

EL34,KT88 150 watt (centre tapped) 2900 ohm - 11,00kg.

%30 , %33 , %40 Ultra Linear options.




Interstage Transformer:

Primer: 10K.ohm
Sekonder:10K.ohm centre tapped.
15Hz-60Khz.
Weight : 250gr.
All of input stage is available.

Choke Coil:

10 Henry /105 ohm / 120mA - 600gr.

15 Henry /147 ohm / 120mA - 600gr.
